Baumer BMMH 30 SSI – MAGRES

The BMMH 30 SSI – MAGRES is a mini absolute encoder from Baumer, designed for high-precision applications. It features a hollow shaft and provides SSI (Serial Synchronous Interface) communication. This encoder uses magnetic sensing for position measurement and offers both single-turn and multi-turn resolutions.

Datasheet

Electrical Ratings:

• Voltage Supply: 10…30 VDC
• Reverse Polarity Protection: Yes
• Consumption w/o Load: ≤50 mA (24 VDC)
• Interface: SSI (Serial Synchronous Interface)
• Function: Singleturn / Multiturn
• Steps per Revolution: Singleturn: 12 bit, Multiturn: 13 bit
• Sensing Method: Magnetic
• Code Sequence: CW: ascending values with clockwise sense of rotation (looking at mounting surface)
• Output Signal | Interface: SSI data: linedriver RS485

Mechanical Design:

• Size (Flange): ø30 mm
• Shaft Type: ø20…27 mm hollow shaft
• Flange: Clamping flange
• Protection EN 60529: IP 67 (at shaft entrance)
• Operating Speed: ≤5000 rpm (mechanical), ≤8000 rpm (electric)
• Starting Torque: ≤0.05 Nm (+20 °C)
• Admitted Shaft Load: ≤40 N axial, ≤60 N radial
• Material: Housing: aluminium; Shaft: stainless steel
• Operating Temperature: -30…+85 °C
• Relative Humidity: 90 % non-condensing
• Resistance: EN 60068-2-6 Vibration 10 g, 55-2000 Hz; EN 60068-2-27 Shock 30 g, 11 ms
• Connection: Connector M16, 7-pin

Advantages

• High Resolution: Provides 12-bit single-turn and 13-bit multi-turn resolutions for precise position measurements.
• Magnetic Sensing: Offers robust and accurate position measurement with magnetic sensing.
• Compact Design: Small size (ø30 mm flange) makes it easy to integrate into various setups.
• High Protection: IP 67 rating ensures reliable performance in harsh environments.
• Shock and Vibration Resistance: High resistance to shock and vibrations ensures durability.

This encoder is perfect for applications requiring a reliable and precise solution, making it a top choice in its category.
