Female connector
SKU:
CAM12.A12-11230360
0.00€
Out of stock
One click request
CAM12.A12-11230360, an M12 female connector with 12 poles designed for high performance. This cable offers a length of 1000 cm, is shielded, and features excellent resistance to chemicals and flames.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11230360 |
| Head A: Connection | M12 |
| Head A: Angle cable outlet | 0° |
| Head A: Gender | Female |
| Head A: Coding | A |
| Head A: No. of poles | 12 |
| Head A: LED | No |
| Head A: Width across flats | AF13 |
| Head A: Tightening torque | 0.6 Nm |
| Head A: Knurled nut material | Zinc-pressure die casting, surface Ni |
| Head A: Body color | Black |
| Labeling sleeve side A | Yes |
| Head B: Connection | Open-ended wires |
| Labeling sleeve side B | Yes |
| Cable length | 1000 cm |
| Length tolerance | В± 15 cm |
| Stripping length | 80 mm |
| Shielded | Yes |
| Conductor structure | 18 x 0.1 mm |
| AWG | 26 |
| External sheath: Material | PUR |
| External sheath: Color | Black |
| Cable diameter | 6.5 mm В± 5% |
| Wire cross section | 0.14 mm² |
| Operating voltage | max. 30 V AC/DC |
| Nominal voltage | 300 V |
| Contact resistance | max. 30 mOhm |
| Operating current per contact | max. 1.5 A |
| Head A: Degree of protection | IP65, IP66K, IP67 |
| Bending radius (mobile) | min. 10 x outer diameter |
| Bending radius (fixed) | min. 5 x outer diameter |
| No. of bending cycles (C-track) | approx. 5000000 Cycles |
| Torsion speed | max. 35 cycles/min |
| Torsion stress in ° | В± 30 °/m |
| No. of torsion cycles | approx. 2000000 Cycles |
| Acceleration (C-track) | max. 5 m/s² |
| Travel speed (C-track) | max. 3.3 m/s |
| Temperature range (mobile) | – 25 …+ 80 °C |
| Temperature range (fixed) | – 25 …+ 80 °C |
| Cable: Temperature range (fixed) | – 40 …+ 80 °C |
| Dragchain capable | Yes |
| Head A: Chemical resistance | No |
| Head A: Flame resistance | HB (UL 94) |
| Head A: Oil resistance | ASTM 1 oil, mineral oils, limited to hydraulic oils |
| Head A: Acid and alkali resistant | No |
| Head A: Pollution degree | 3 |
| Cable: Chemical resistance | Good (DIN EN 60811-404) |
| Cable: Flame resistance | Conform UL 1581 §1090 (H); CSA FT2; IEC 60332-2-2 |
| Cable: Oil resistance | Good (DIN EN 60811-404) |
| Cable: Silicone-free | Yes |
This connector is designed for durability and reliability in various applications, ensuring optimal performance even in harsh environments. It is dragchain capable, making it suitable for dynamic installations.
