DAB10-AI measuring amplifier, designed for precise current output and featuring a digital IO-Link interface.
With capabilities for analog force measurement and custom parameterization, this device is perfect for various industrial applications.
| Baumer Article no | 11237419 |
| Output signal | 4 … 20 mA IO-Link |
| Non-linearity | < 0.04 % |
| Repeatability | < 0.01 % |
| Temperature effect zero | < 0.01 % / 10K |
| Material housing | Aluminium, 6060, chem. passivated |
| Electrical connection on sensor side | M8, 4 pin, female |
| Electrical connection on control side | M12, 5 pin, male |
| Operating temperature range | -40 … 85 °C |
| Storage temperature range | -40 … 85 °C |
| Protection class EN 60529, ISO20653 | IP 65 |
| Vibration IEC 60068-2-6 | 10 … 57 Hz: 1.5 mm p-p, 58 … 2000 Hz: 10 g |
| Random IEC 60068-2-64 | 20 … 1000 Hz: 0.1 gВ²/Hz |
| Shock IEC 60068-2-27 | 50 g / 11 ms, 100 g / 6 ms |
| Bridge resistance | ≥ 350 © |
| Signal area | ± 3.8 mV/V |
| Power supply | 2.5 VDC |
| Supply voltage | 18 … 30 VDC |
| Current consumption | < 40 mA |
| Resolution ADC | 24 bit |
| Sampling rate input | 8 kS/s |
| Sampling rate output analog | 8 kS/s |
| Cut-off frequency (3 db) | 1 kHz |
| SNR @1.0 mV/V | > 75 dB |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Max. Output range | 0 … 22 mA |
| IO-Link version | 1.1 |
| IO-Link port type | Class A |
| Baud rate | 230,4 kbaud (COM3) |
| Process data length | 32 bit |
| Cycle time | ≥ 1 ms |
| SIO-mode | Yes |
| Process data (cyclic) | Process ValueScale exponentSSC 1SSC 2QualityAlarm |
| Parameterizable | Process inputUnit (N, kg, µm/m) selectableTeach-in Offset/ TareCorrelation to known forceAnalog output signalOutput range analog signalAlarm state analog signalFunctions I/O’s selectable |
| Additional functions | Low pass filterPeak value memorySample and holdTwo digital switching points (SSC)Remote operation |
| Additional data | Diagnostic dataError detection |
| Conformity | CEUL |
This measuring amplifier stands out for its robust design and versatile functionality, making it suitable for demanding environments.
Enjoy exceptional accuracy and reliability with this product, ensuring optimal performance in your applications.
