Baumer DAB10-AU, a versatile measuring amplifier featuring a +/- 10 V voltage output.
This device enables precise analog force measurement with an advanced digital IO-Link interface, ensuring individual and application-specific parameterization.
| Baumer Article no | 11237418 |
| Output signal | В± 10 VDC IO-Link |
| Non-linearity | < 0.01 % |
| Repeatability | < 0.01 % |
| Temperature effect zero | < 0.01 % / 10K |
| Material housing | Aluminium, 6060, chem. passivated |
| Electrical connection on sensor side | M8, 4 pin, female |
| Electrical connection on control side | M12, 5 pin, male |
| Operating temperature range | -40 … 85 В°C |
| Storage temperature range | -40 … 85 В°C |
| Protection class EN 60529, ISO20653 | IP 65 |
| Vibration IEC 60068-2-6 | 10 … 57 Hz: 1.5 mm p-p, 58 … 2000 Hz: 10 g |
| Random IEC 60068-2-64 | 20 … 1000 Hz: 0.1 gВ²/Hz |
| Shock IEC 60068-2-27 | 50 g / 11 ms, 100 g / 6 ms |
| Bridge resistance | 350 © |
| Signal area | В± 3.8 mV/V |
| Power supply | 2.5 VDC |
| Supply voltage | 18 … 30 VDC |
| Current consumption | < 40 mA |
| Resolution ADC | 24 bit |
| Sampling rate input | 8 kS/s |
| Sampling rate output analog | 8 kS/s |
| Cut-off frequency (3 db) | 1 kHz |
| SNR @1.0 mV/V | > 75 dB |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Max. Output range | В± 11 VDC |
| Output current | < 100 mA |
| IO-Link version | 1.1 |
| IO-Link port type | Class A |
| Baud rate | 230,4 kbaud (COM3) |
| Process data length | 32 bit |
| Cycle time | 1 ms |
| SIO-mode | Yes |
| Process data (cyclic) | Process ValueScale exponentSSC 1SSC 2QualityAlarm |
| Parameterizable | Process inputUnit (N, kg, Вµm/m) selectableTeach-in Offset/ TareCorrelation to known forceAnalog output signalOutput range analog signalAlarm state analog signalFunctions I/O’s selectable |
| Additional functions | Low pass filterPeak value memorySample and holdTwo digital switching points (SSC)Remote operation |
| Additional data | Diagnostic dataError detection |
| Conformity | CEUL |
This measuring amplifier is designed for optimal performance in various environments, making it a reliable choice for sensitive applications. With its advanced features and robust construction, the DAB10-AU is an excellent solution for those needing precise and adaptable measurement capabilities.
