Optimize your motor safety with the Motor earthing unit ATEX/IECEx, designed for hazardous environments. This unit effectively prevents leakage of parasitic shaft currents while adhering to strict ATEX and IECEx standards.
This motor earthing unit is suitable for hollow shafts with diameters ranging from 20 to 42 mm. It operates under extreme conditions with a temperature range of -60 to +60 °C and supports current loads of up to 12 A. The unit boasts an impressive operating speed of up to 8500 rpm and a protection rating of IP 56, ensuring reliable performance in challenging environments.
| Current load | 1 A12 A (short-term) |
| Operating speed | 8500 rpm |
| Ambient temperature | -60…+50 °C (T5)-60…+60 °C (T4) |
| Admitted shaft load | 150 N axial200 N radial |
| Rotor moment of inertia | 3.7 kgcm² |
| Operating torque | 15 Ncm |
| Protection EN 60529 | IP 56 |
| Explosion protection | II 2 G Ex db IIC T4/T5 GbEx db IIC T4/T5 Gb |
| Weight approx. | 3.5 kg |
| Shaft type | Ø20…42 mm (through hollow shaft) |
| Material | Housing: aluminium |
| Resistance | IEC 60068-2-6 Vibration 10 g, 50-2000 Hz IEC 60068-2-27 Shock 100 g, 6 ms |
| Approval | CE ATEX IECEx |
