Electronic speed switch
SKU:
ES 93
0.00€
Out of stock
One click request
Monitor your speed with the Electronic Speed Switch, ideal for various applications.
It features three adjustable threshold speeds and independent transistor outputs for precise control.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11054943 |
| Voltage supply | 12 VDC В±10 % |
| Consumption w/o load | 5 mA |
| Switching accuracy | В± 4 % (1500 rpm) В± 2 % (>1500 rpm) |
| Switching hysteresis | = 30 % of switching speed |
| Switching outputs | 3 outputs, speed control |
| Current each output | 40 mA (DC) |
| Switching delay time | 40 ms |
| Interference immunity | EN 61000-6-2 |
| Emitted interference | EN 61000-6-3 |
| Approval | CE |
| Size (flange) | ø115 mm |
| Shaft type | ø11 mm solid shaft |
| Flange | EURO flange B10 |
| Protection EN 60529 | IP 55 |
| Speed (n) | 5000 rpm |
| Range of switching speed (ns) | 200…5000 rpm |
| Operating torque | 2 Ncm |
| Rotor moment of inertia | 0.125 kgcmВ² |
| Admitted shaft load | 150 N axial250 N radial |
| Operating temperature | -20…+85В В°C |
| Weight approx. | 1.3 kg |
| Connection | Terminal box |
| Material | Housing: aluminium die-cast; Shaft: stainless steel |
This Electronic Speed Switch is designed for efficient speed monitoring in various applications, ensuring high performance and reliability. Its robust design is suitable for a wide range of operating conditions, making it a versatile choice for your needs.
