FHDM 16P5004 diffuse sensors designed with background suppression technology. Ideal for precise detection in varying environments, these sensors ensure optimal performance.
The FHDM 16P5004 diffuse sensors utilize a pulsed red LED light source and feature a sensing distance of 20 … 600 mm, making them versatile for a range of applications. With an operating temperature range of -25 … +65 °C, they are suitable for both indoor and outdoor use. The sensors also include features such as short circuit protection and reverse polarity protection, ensuring reliability and safety in operation.
| output current | < 200 mA |
| connection types | cable 4 pin, 2 m |
| sensing distance Tw | 20 … 600 mm |
| response time / release time | < 5 ms |
| height / length | 50 mm |
| type | background suppression |
| width / diameter | 15,4 mm |
| short circuit protection | yes |
| output function | light / dark operate |
| reverse polarity protection | yes |
| current consumption typ. | 29 mA |
| light source | pulsed red LED |
| sensing distance adjustment | mechanical, 5 turn |
| voltage supply range +Vs | 10 … 30 VDC |
| front (optics) | PMMA |
| current consumption max. (no load) | 41 mA |
| light indicator | LED yellow |
| sensing range Tb (at Tw min.) | 5 … 20 mm |
| housing material | die-cast zinc |
| suppression of reciprocal influence | yes |
| protection class | IP 67 |
| voltage drop Vd | < 1,8 VDC |
| depth | 50 mm |
| manufacter SKU | FHDM 16P5004 |
| output circuit | PNP |
| operating temperature | -25 … +65 °C |
| wave length | 660 nm |
| type | rectangular |
| sensing range Tb (at Tw max.) | 20 … 600 mm |
