Tacho generator GT 7.08 is designed for high precision and reliability. With a reversal tolerance of ≤0.1% and a linearity tolerance of ≤0.15%, it ensures accurate performance in various applications.
| Shaft type | ø12…16 mm (blind hollow shaft) |
| manufacter SKU | GT 7.08 |
| Connection | Screw terminal connector Cable 0.6 m |
| Open-circuit voltage | 10…60 mV per rpm |
| Materials | Housing: stainless steel / plastic Shaft: stainless steel |
| Approval | CE |
| Torque | 1.5 Ncm |
| Calibration tolerance | ±5 % |
| Armature-circuit time-constant | |
| Operating temperature | -30…+130 °C |
| Resistance | IEC 60068-2-6 Vibration 10 g, 10-2000 Hz IEC 60068-2-27 Shock 100 g, 6 ms |
| Rotor moment of inertia | 0.4 kgcm² |
| Climatic test | Humid heat, constant (IEC 60068-2-3, Ca) |
| Size (flange) | ø70 mm |
| Protection DIN EN 60529 | IP 55 |
| Reversal tolerance | ≤0.1 % |
| Emitted interference | EN 61000-6-3 |
| Temperature coefficient | ±0.05 %/K (open-circuit) |
| Linearity tolerance | ≤0.15 % |
| Interference immunity | EN 61000-6-2 |
| Isolation class | B |
| Weight approx. | 110 g |
| Performance | 0.3 W (speed ≥5000 rpm) |
This Tacho generator is built for durability and precision, making it an ideal choice for various industrial applications. Its robust design ensures reliable operation under demanding conditions, while the compact size makes it easy to integrate into existing systems.
