Precision sine multiplier
SKU:
HEAG 159
0.00€
Out of stock
One click request
Precision Sine Multiplier effectively converts SinCos signals into multiplied SinCos signals. With a multiplying factor that ranges from 1 to 128, it ensures high signal quality and precise adjustments.
Manufacturer:
Baumer
Description:
| Voltage supply | 5 VDC ±5 %10…30 VDC |
| Consumption | 500 mA (5 VDC)300 mA (10…30 VDC) |
| Inputs | SinCos2x SinCos |
| Input signals | A+, A-, B+, B-, R+, R- |
| Outputs | SinCosError output |
| Output signals | A+, B+, R+, A-, B-, R-Option: A+, B+, R+, A-, B-, R-, Error- |
| Output frequency | 600 kHz |
| Amplitude resolution | 12 bit |
| Interpolation factor for SinCos output (multiplying) | 1…128 |
| Approval | CE |
| Dimensions W x H x L | 122 x 122 x 80 mm |
| Protection EN 60529 | IP 65 |
| Operating temperature | 0…+50 °C |
| Resistance | IEC 60068-2-6Vibration 1 g, 50-2000 HzIEC 60068-2-27Shock 30 g, 11 ms |
| Weight approx. | 1 kg |
| Connection | Connector M23, 12-pinConnector, 3-pin, external voltage supply |
This device is designed for precision applications requiring reliable signal conversion and high-quality output. The robust construction and advanced features ensure optimal performance in various industrial environments.
