Fiber-optic receiver ensures interference-free transmission of square-wave signals, making it ideal for high interference locations.
It features easy-to-fit plugs for each channel and effectively reconverts optical signals back to electrical signals in control cabinet.
This Fiber-optic receiver is designed for reliable performance even in challenging environments. Voltage supply for HEAG 173 is 5 VDC В±5%, while HEAG 174 operates between 9 to 26 VDC. With a consumption of only 60 mA, it supports 3 x fiber-optic inputs and provides multiple output signals, including inverted options.
Transmission frequencies can reach up to 250 kHz over lengths of 300 m, and the device is CE approved, ensuring compliance with safety standards. The compact dimensions of 50 x 75 x 55 mm and IP 20 protection rating make it suitable for various applications.
Its versatility is highlighted by compatibility with different fiber optic cables, including PCF 200 μm and silica fibers. The screw terminal connector allows for easy installation with options for various connector types.
