Baumer HXG20 is a high-performance industrial camera featuring a resolution of 2048 x 1088 pixels. With its advanced ams (CMOSIS) CMV2000 sensor, it achieves an impressive frame rate of 105 fps, making it ideal for dynamic imaging applications.
The Baumer HXG20 is a Dual GigE, 2 Megapixel monochrome camera designed for demanding industrial applications. It boasts a global shutter for capturing fast-moving objects without motion blur. With a robust aluminum housing, it operates efficiently in a range of environments, maintaining performance even under challenging conditions.
| Baumer Article no | 11080593 |
| Sensor | ams (CMOSIS) CMV2000 |
| Mono/Color | Mono |
| Sensor type | 2/3″ CMOS |
| Shutter type | Global shutter |
| Resolution | 2048 x 1088 px |
| Pixel size | 5.5 x 5.5 Вµm |
| Exposure time | 0.02 … 1000 ms |
| Image formats, interface frame rate max. | Full Frame, 2048 x 1088 px, max. 105 fpsBinning 2×1, 1024 x 1088 px, max. 211 fpsSubsampling 2×2, 1024 x 544 px, max. 421 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 2048 x 1088 px, max. 337 fps |
| Pixel formats | Mono8Mono10Mono12 |
| Analog controls | Gain (0 … 12 dB)Offset (0 … 255 LSB) |
| Color models | Mono |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 512 trigger signals |
| Sequencer | Automated control for series of images using different sets of parameters |
| Sequencer parameter | Exposure timegain factorOutput |
| Digital inputs | 3 input line (each with Debouncer) |
| Digital outputs | 3 output lines |
| Internal image buffer | 256 MB |
| Data interface | Dual Gigabit Ethernet, Transfer rate 2000 Mbits/sec, Connector: 2 x 8P8C Modular Jack (RJ45), screwable type |
| Process interface | M8 / 8 pins |
| Power supply | via M8 / 3 pins |
| Lens mount | C-mount (F-mount on request) |
| Width | 52 mm |
| Height | 52 mm |
| Depth | 55 mm |
| Weight | 232 g |
| Material | housing: aluminum |
| Voltage supply range +Vs | 20 … 30 V DC (external power supply)38 … 57 V DC (Power over Ethernet) |
| Power consumption | approx. 7,7 W @ 24 VDC and 105,0 fpsapprox. 8,9 W @ 48 VDC (PoE) and 105,0 fps |
| Operating temperature | +5 … +50 В°C |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Conformity | CERoHSFCCEAC |
