Distance sensor
SKU:
IF08.D03L-Q25.GP1I.7VCU
0.00€
Out of stock
One click request
Baumer Distance Sensor, article number 11214892. This precision device measures distances from 0 to 3 mm, making it ideal for a variety of applications.
- Features PNP / push-pull output and IO-Link connectivity.
- Durable cable length of 2m and operating temperature range of -20 to 70 °C.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11214892 |
| Mounting type | Quasi-flush |
| Special type | Linearized |
| Type | Distance measuring |
| Measuring distance Sd | 0 … 3 mm |
| Resolution | < 0.005 mm (High Accuracy Mode) |
| Repeat accuracy | 0.01 mm |
| Adjustment | IO-Link |
| Teach | Single point, Two point, Window |
| Linearity error | В± 10 µm (S = 0 … 2 mm) В± 90 µm (S = 0 … 3 mm) |
| Temperature drift | В± 2 % (Full Scale; S = 0 … 2 mm)В± 6 % (Full Scale; S = 0 … 3 mm) |
| Hysteresis | < 99 % (adjustable) |
| Response time (factory characteristic) | < 1 ms |
| Switching frequency | 1.25 kHz |
| Voltage supply range +Vs | 8 … 30 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | PNP Push-pull IO-Link |
| Output current | < 50 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Type | Rectangular |
| Housing material | Stainless steel |
| Dimension | 8 mm |
| Housing length | 24.6 mm |
| Connection types | Cable PUR, 2 m |
| Tightening torque max. | 0.8 Nm |
| Operating temperature | -20 … +70 °C |
| Protection class | IP 67 |
| Interface | IO-Link V1.1 |
| Baud rate | 230,4 kBaud (COM 3) |
| Cycle time | 0.6 ms |
| Process data length | 32 Bit |
| Process data structure | Bit 0 = SSC1 (distance) Bit 1 = SSC2 (distance) Bit 3 = alarm Bit 4 = SSC3 (frequency) Bit 5 = SSC4 (counter) Bit 16-31 = 16 Bit measurement |
| IO-Link port type | Class A |
| Adjustable parameters | Measuring range Switching point Switching hysteresis Measured value filtering Time filters Output logic Output circuit Counter Deactivate the sensor element |
| Additional data | Distance Frequency Operating cycles Operating hours Boot cycles Operating voltage Device temperature Histograms |
This distance sensor is designed for high accuracy and reliability, making it suitable for various industrial applications. With its robust stainless steel housing and IP67 protection class, it can withstand harsh environmental conditions.
