Out of stock
Compact and efficient Inductive proximity switch, perfect for precise applications. With a nominal sensing distance of 1 mm, this sensor features an NPN make function (NO) and is equipped with durable 0.5 m wires.
| Baumer Article no | 11166747 |
| Mounting type | Flush |
| Nominal sensing distance Sn | 1 mm |
| Temperature drift | – 5 % / + 10 % (+10 … +60 В°C)- 5 % / + 15 % (-10 … +70 В°C) |
| Hysteresis | 2 … 20 % of Sr |
| Output indicator | LED red |
| Switching frequency | 4 kHz |
| Voltage supply range +Vs | 6 … 30 VDC |
| Current consumption max. (no load) | 10 mA |
| Output circuit | NPN make function (NO) |
| Voltage drop Vd | < 2 VDC |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Type | Cylindrical smooth |
| Material (sensing face) | POM |
| Housing material | Stainless steel |
| Dimension | 3 mm |
| Housing length | 12 mm |
| Connection types | Wires, 0,5 m |
| Operating temperature | -10В …В +70 В°C |
| Protection class | IP 67 |
This sensor is designed to operate efficiently in temperatures ranging from -10 to +70 °C, making it suitable for various environments. Its IP 67 rating ensures protection against dust and water, enhancing its durability. Ideal for automation and control systems, the Baumer Inductive proximity switch is a reliable choice for your sensing needs.
