Distance sensor
SKU:
IR08.D03L-F46.GP1I.7SL
0.00€
Out of stock
One click request
Distance Sensor, article number 11193947, designed for precision measurement in tight spaces.
- Accurate measurements ranging from 0 to 3 mm
- Features PNP/push-pull output and IO-Link connectivity
Manufacturer:
Baumer
Description:
| Baumer Article no | 11193947 |
| Mounting type | Flush |
| Special type | Linearized |
| Type | Distance measuring |
| Measuring distance Sd | 0 … 3 mm |
| Resolution | < 0.005 mm (High Accuracy Mode) |
| Repeat accuracy | 0.01 mm |
| Adjustment | IO-Link |
| Teach | Single point, Two point, Window |
| Linearity error | В± 10 µm (S = 0 … 2 mm) В± 50 µm (S = 0 … 3 mm) |
| Temperature drift | В± 2 % (Full Scale; S = 0 … 2 mm)В± 4 % (Full Scale; S = 0 … 3 mm) |
| Hysteresis | < 99 % (adjustable) |
| Power on indication | LED green |
| Output indicator | LED yellow |
| Response time (factory characteristic) | < 1 ms |
| Switching frequency | 1.25 kHz |
| Voltage supply range +Vs | 8 … 36 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | PNP Push-pull IO-Link |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Type | Cylindrical threaded |
| Housing material | Stainless steel |
| Dimension | 8 mm |
| Housing length | 46 mm |
| Connection types | Connector M8 |
| Tightening torque max. | 10 Nm (A: 7 Nm) |
| Operating temperature | -25 … +75 °C |
| Protection class | IP 67 |
| Interface | IO-Link V1.1 |
| Baud rate | 230,4 kBaud (COM 3) |
| Cycle time | 0.6 ms |
| Process data length | 32 Bit |
| Process data structure | Bit 0 = SSC1 (distance) Bit 1 = SSC2 (distance) Bit 3 = alarm Bit 4 = SSC3 (frequency) Bit 5 = SSC4 (counter) Bit 16-31 = 16 Bit measurement |
| IO-Link port type | Class A |
| Adjustable parameters | Measuring range Switching point Switching hysteresis Measured value filtering Time filters LED status indicators Output logic Output circuit Counter Deactivate the sensor element Find Me function |
| Additional data | Distance Frequency Operating cycles Operating hours Boot cycles Operating voltage Device temperature Histograms |
With a robust stainless steel housing and IP67 protection class, this sensor is built to perform in harsh environments. Its advanced features, including adjustable parameters and a wide operating temperature range, make it ideal for various industrial applications.
