linearized Inductive distance sensor
SKU:
IR12.D06L-Q60.IA1E.7BF
0.00€
Out of stock
One click request
Inductive distance sensors – linearized, featuring a measuring range of 0 to 6 mm.
- Equipped with a current output for versatile applications.
- Designed with external Teach-in functionality for user-friendly setup.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11157693 |
| Mounting type | Quasi-flush |
| Special type | Linearized |
| Measuring distance Sd | 0 … 6 mm |
| Sensitivity | 2.67 mA/mm |
| Resolution | < 0.003 mm (stat.) < 0.005 mm (dynam., S = 0 ... 4 mm) < 0.022 mm (dynam., S = 0 ... 6 mm) |
| Repeat accuracy | 0.01 mm |
| Adjustment | External Teach-in |
| Teach | 1-point analog, 2-point analog, factory reset |
| Linearity error | В± 25 µm (S = 0 … 4 mm) В± 120 µm (S = 0 … 6 mm) |
| Temperature drift | В± 2 % (Full Scale; S = 0 … 4 mm) В± 5 % (Full Scale; S = 0 … 6 mm) |
| Teach-Feedback | LED yellow |
| Response time (factory characteristic) | < 1 ms |
| Voltage supply range +Vs | 8 … 36 VDC |
| Current consumption max. (no load) | 25 mA |
| Output circuit | Current output |
| Output signal | 4 … 20 mA |
| Load resistance | < 50 Ohm/V * Vs - 250 Ohm > 500 Ohm (Vs = 30 … 36 VDC) |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Type | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Dimension | 12 mm |
| Housing length | 60 mm |
| Connection types | Connector M12 |
| Tightening torque max. | 15 Nm (A: 10 Nm) |
| Operating temperature | -25 … +75 °C (Vs = 8 … 30 VDC) -25 … +60 °C (Vs = 8 … 36 VDC) |
| Protection class | IP 67 |
This sensor is ideal for applications requiring high precision and reliability in measurement. With its robust design and protection class IP 67, it can operate effectively in various environmental conditions.
