Magnetic HeavyDuty encoder is designed for robust performance and durability. It features fully encapsulated electronics for superior protection and offers large tolerances for easy integration in various applications.
Magnetic sensing / Through hollow shaft max. diam. 180 mm
| Interference immunity | EN 61000-6-2 |
| Emitted interference | EN 61000-6-3 |
| Approval | CEUL approval / E217823Option: DNV approval |
| Voltage supply | 4.75…30 VDC |
| Consumption w/o load | 70 mA |
| Pulses per revolution | 128 … 8192 |
| Phase shift | 90 ° ±10° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Magnetic |
| Output frequency | 300 kHz |
| Output signals | A+, B+, R+, A-, B-, R- |
| Output stages | HTLTTL/RS422 |
| Voltage supply | 5 VDC |
| Consumption w/o load | 70 mA |
| Sinewave cycles per revolution | 128 |
| Phase shift | 90 ° ±5° |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Magnetic |
| Output signals | A+, B+, R+, A-, B-, R- |
| Output stages | SinCos 1 Vpp |
| Difference of SinCos amplitude | 20 mV |
| Harmonics typ. | -40 dB |
| DC offset | 20 mV |
| Sensor head | Standard signal processing |
| Size (flange) | ø201.7 mm |
| Shaft type | ø50…180 mm (through hollow shaft) |
| Axial tolerance | ±3 mm (wheel/head) |
| Radial tolerance | 0.1…2.2 mm (wheel/head) |
| Protection EN 60529 | IP 67 (head)IP 68 (wheel) |
| Operating speed | 4000 rpm |
| Material | Housing sensing head: aluminium alloyWheel: stainless steel (1.4104, option DNV: 1.4313) |
| Operating temperature | -40…+100 °C |
| Resistance | IEC 60068-2-6Vibration 30 g, 55-2000 HzIEC 60068-2-27Shock 300 g, 2 ms |
| Accuracy of magnetic measure | ±150 ″ |
| Connection | Flange connector M23, 12-pinTerminal box |
With its robust design and advanced features, the Magnetic HeavyDuty encoder ensures reliable performance in demanding environments. Its compact dimensions allow for easy integration, making it an ideal choice for various applications.
