Distance Sensor, art. 11199077, designed for precise distance measuring from 30 to 300 mm. This sensor features a pulsed PinPoint LED and offers robust solutions with Teach-in and IO-Link capabilities.
| Baumer Article no | 11199077 |
| Type | Distance measuring |
| Version | IO-Link measuring |
| Measuring distance Sd | 30 … 300 mm |
| Adjustment | Teach-in and IO-Link |
| Power on indication | LED green |
| Light indicator | LED yellow |
| Resolution | 500 … 5000 µm |
| Linearity error | В± 1.5 … 15 mm |
| Beam type | Point |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2° |
| Temperature drift | < 0,2 % Sde/K |
| Light source | Pulsed PinPoint LED |
| Wave length | 630 nm |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Voltage drop Vd | < 3 VDC |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | IO-Link V1.1 |
| Baud rate | 38,4 kBaud (COM 2) |
| Cycle time | 2.7 ms |
| Process data length | 3 Byte |
| Process data structure | Bit 0 = BDC1Bit 2 = qualityBit 3 = alarmBit 8-23 = 16 Bit measurement |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Type | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Protection class | IP 67 |
| Operating temperature | -25 … +60 °C |
This Distance Sensor is engineered to deliver reliable performance in challenging environments, with a wide temperature range and high protection class. Ideal for various industrial applications, it ensures precise measurements and robust functionality.
