Miniature Through beam sensors
SKU:
O300.EL-GW1B.72CU
0.00€
Out of stock
One click request
Miniature through beam sensors designed for precision and reliability. With a range of 40 meters and a robust IP67 rating, this receiver sensor is perfect for various industrial applications.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11176842 |
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 40 m |
| Nominal range Sn | 75 m |
| Alignment / soiled lens indicator | Flashing light indicator |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | qTeach / remote |
| Alignment optical axis | < 2° |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | < 3 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Type | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 … +60 °C |
| Protection class | IP 67 |
This sensor is engineered for high performance and durability in challenging environments. Its compact design makes it suitable for tight spaces while ensuring effective operation across various conditions.
