Fork sensors
SKU:
OG030U.R-GW1O.7WL
0.00€
Out of stock
One click request
Fork sensor featuring a through beam design.
With a detection range of 30 mm and a robust IP 67 rating, these sensors are ideal for various applications.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11229489 |
| Type | Through beam sensor |
| Object size | > 0.5 mm |
| Repeat accuracy | 0.02 mm |
| Response time / release time | < 0.1 ms |
| Hysteresis | < 0.25 mm |
| Sensitivity adjustment | Potentiometer, 270°IO-Link |
| Light source | Pulsed red LED |
| Wave length | 660 nm |
| Light indicator | LED yellow |
| IO-Link | Yes |
| Interface | IO-Link V1.1 |
| Baud rate | 38,4 kBaud (COM 2) |
| Switching frequency | 5000 Hz , default1500 Hz 250 Hz 8000 Hz |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 30 mA |
| Output function | Light / dark operate switchable |
| Output circuit | Push-pull / IO-Link |
| Voltage drop Vd | < 2.8 VDC |
| Output current | < 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 50 mm |
| Fork width Sb | 30 mm |
| Height / length | 60 mm |
| Penetration depth | 35 mm |
| Depth | 10 mm |
| Type | U profile |
| Housing material | Die-cast zinc |
| Connection types | Connector M8, 3 pin |
| Operating temperature | -25 … +60 °C |
| Protection class | IP 67 |
This sensor is designed for high performance in various environments, ensuring reliability and durability with its die-cast zinc housing.
Equipped with advanced IO-Link technology, it allows for easy integration into smart systems, enhancing automation processes.
