High performance sensor
SKU:
OM70-L1000.HH1000.EK
0.00€
Out of stock
One click request
Discover the High performance sensor , designed for precise distance measurement. Equipped with adjustable reference distances and configurable outputs, it meets various industrial needs.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11216516 |
| Type | Distance measuring |
| Version | OM70 laser line basic |
| Measuring distance Sd | 100В …В 1000 mm |
| Measuring range Mr | 900 mm |
| Sweet spot | 1000 mm |
| Adjustment | Webserver, Ethernet TCP/IP |
| Power on indication | LED green |
| Output indicator | LED yellow / LED red |
| Ethernet link indication | LED blue |
| Resolution | 3 … 63 Вµm |
| Repeat accuracy | 1 … 32 Вµm |
| Linearity error | В± 0.19 % Mr |
| Beam type | Line |
| Temperature drift | 0,065 % Sde/K |
| Hysteresis digital output | Adjustable |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Laser class | 1 |
| Response delay | 0.8 ms |
| Measuring frequency | 2000 Hz |
| Voltage supply range +Vs | 15 … 28 VDC |
| Current consumption max. (no load) | 75 mA |
| Output circuit | Analog and digital |
| Output signal | 4 … 20 mA / 2 … 10 mA / 0 … 10 VDC / 0В …В 5В VDC |
| Output current | < 100 mA |
| Switching output | Push-pull |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | Ethernet TCP/IP |
| Protocol | Profinet (Class B), Modbus TCP, OPC UA, UDP streaming, EtherNet/IP |
| Webserver | Yes |
| Width / diameter | 26 mm |
| Height / length | 74 mm |
| Depth | 55 mm |
| Type | Rectangular, front view |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin & M12 4 pin |
| Weight | 135 g |
| Ambient light immunity | < 100 kLux |
| Protection class | IP 67 |
| Operating temperature | -10В …В +50 В°C |
| Storage temperature | -20В …В +60 В°C |
| Vibration (sinusoidal) | IEC 60068-2-6:20081 mm p-p at f = 10 – 55 Hz, duration 5 min per axis30 min endurance at f = 55 Hz per axis |
| Shock (semi-sinusoidal) | IEC 60068-2-27:200930 g / 11 ms, 6 jolts per axis and direction |
This high-performance sensor is ideal for industrial applications requiring accuracy and reliability. With features like adjustable settings and a robust design, it ensures optimal performance in various environments.
