Discover the exceptional capabilities of the High Performance Sensor, article number 11195788. This advanced distance sensor features a touch display with a Live Monitor function, ensuring precise measurements in various applications.
- Configurable switching output for tailored functionality
- Selectable filters and trigger modes for enhanced adaptability
| Baumer Article no | 11195788 |
| Type | Distance measuring |
| Version | OM70 laser line basic |
| Measuring distance Sd | 100В …В 1000 mm |
| Measuring range Mr | 900 mm |
| Sweet spot | 1000 mm |
| Adjustment | Touch Display, RS485 |
| Power on indication | LED green |
| Output indicator | LED yellow / LED red |
| Resolution | 3 … 63 Вµm |
| Repeat accuracy | 1 … 32 Вµm |
| Linearity error | В± 0.19 % Mr |
| Beam type | Line |
| Temperature drift | 0,065 % Sde/K |
| Hysteresis digital output | Adjustable |
| Light source | Pulsed red laser diode |
| Wave length | 660 nm |
| Laser class | 1 |
| Response delay | 0.8 ms |
| Measuring frequency | 2500 Hz |
| Voltage supply range +Vs | 15 … 28 VDC |
| Current consumption max. (no load) | 75 mA |
| Output circuit | Analog and RS 485 |
| Output signal | 4В …В 20В mA / 0В …В 10В VDC |
| Output current | < 100 mA |
| Switching output | Push-pull |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | RS485 |
| Baud rate | 115200, adjustable |
| Width / diameter | 26 mm |
| Height / length | 74 mm |
| Depth | 55 mm |
| Type | Rectangular, front view |
| Housing material | Aluminum |
| Front (optics) | Glass |
| Connection types | Connector M12 8 pin |
| Weight | 130 g |
| Ambient light immunity | < 100 kLux |
| Protection class | IP 67 |
| Operating temperature | -10В …В +50 В°C |
| Vibration (sinusoidal) | IEC 60068-2-6:20081 mm p-p at f = 10 – 55 Hz, duration 5 min per axis30 min endurance at f = 55 Hz per axis |
| Shock (semi-sinusoidal) | IEC 60068-2-27:200930 g / 11 ms, 6 jolts per axis and direction |
This sensor is designed for precision and reliability, making it ideal for various industrial applications. Its robust construction ensures durability under challenging conditions, while the advanced features enhance its usability in diverse environments.
