Through beam sensor
SKU:
OR18.EL-PV1P.7BO
0.00€
Out of stock
One click request
OR18.EL-PV1P.7BO Through Beam Sensor, perfect for precise object detection.
This receiver sensor operates effectively up to 55 meters with a PNP complementary output.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11157817 |
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 55 m |
| Nominal range Sn | 60 m |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | Potentiometer, 270° |
| Response time / release time | < 0.34 ms |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Current consumption typ. | 35 mA |
| Voltage drop Vd | < 2 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP complementary |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 81.5 mm |
| Type | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -10 … +55 °C |
| Protection class | IP 67 |
This durable sensor is ideal for a variety of industrial applications, ensuring reliable performance even in challenging environments.
With features like short circuit protection and reverse polarity protection, it guarantees safety and efficiency in operation.
