Profile camera, a precision tool designed for high-quality 2D point cloud output. This device offers seamless calibration and intuitive parameterization through its user-friendly web interface.
| Baumer Article no | 11218604 |
| Type | Measuring mode: Profile in x-z |
| Measurement range MR | 50 mm |
| Clearance distance | 100 mm |
| Working range (Sdc … Sde) | 100 … 150 mm |
| Reference distance | 125 mm |
| Field of view (@Sdc … Sde) | 48 mm … 72 mm |
| Resolution X (@Sdc … Sde) | 80 … 120 Вµm |
| Profiles per second | 200 … 800 Hz |
| Profile points | 600 pixel |
| Resolution Z (@Sdc … Sde) | 8 … 15 Вµm |
| Repeat accuracy Z | 4 Вµm |
| Linearity deviation Z | В± 0.1 % MR |
| Temperature drift | В± 0.04 %Sde/K |
| Laser class | 2 |
| Laser wavelength | Red (660 nm) |
| Max. laser power | 4.5 mW |
| Light point shape (at reference distance) | Line Length (x) 72 mmLine Width (z) < 100 Вµm |
| Software / parametrisation | Integrated Webserver for parametrisation |
| Interfaces / output circuit | Fast Ethernet 100-MBit/s |
| Protocols | UDP, SDK (C#, C++, .NET, Python) |
| Voltage supply range +Vs | 18 … 30 VDC |
| Switching outputs | 1 x Alarm Output (Push Pull) |
| Power supply | typ. 2.4W (100 mA max at 24 V)IEEE 802.3af Power over Ethernet (PoE) |
| Electrical connection | M12 12-pol, A-coded, male |
| Ethernet connection | M12 8-pol, X-coded, female |
| Encoder input specifications | 4 Inputs Differential: A/BHTL / TTL availableHigh Level: 2.5 V … +Ub / PoE 2.5 … 24 VLow Level: < 1.5 VMax. Frequency 30kHz |
| Trigger input specification | High Level: 8 V … +Ub / PoE 8 … 24 VLow Level: < 2.5 V |
| Material | Case: Aluminium, Front Cover: Glass |
| Dimensions (W x H x D) | 36 mm x 74 mm x 60 mm |
| Width | 36 mm |
| Height | 74 mm |
| Depth | 60 mm |
| Weight | 270 g |
| Ambient temperature | 0 … + 45 В°C |
| Storage temperature | – 10 … + 60 В°C |
| Ambient humidity | 20 … 85 % |
| Protection class (IEC 60529) | IP65 |
| Vibration (sinusoidal) | 1 mm p-p at f = 10 – 55 Hz, duration 5 min per axis30 min endurance at f = 55 Hz per axisIEC 60068-2-6:2008 |
| Shock (semi-sinusoidal) | 30 g / 11 ms, 6 jolts per axis and directionIEC 60068-2-27:2009 |
| Ambient light immunity | < 25 kLux |
| Conformity | CEUL |
This advanced camera is ideal for a variety of industrial applications, ensuring accurate measurements and reliable performance. With features such as a fast Ethernet connection and a comprehensive SDK, it is tailored for seamless integration into your systems.
