Baumer OZDM 16N1001/S14 diffuse contrast sensor, designed for precise object detection. With a pulsed red laser diode, it ensures reliable performance within a sensing distance of 0 to 250 mm.
The Baumer OZDM 16N1001/S14 optical sensor is used to detect various objects by receiving the emitter light reflected from them. The model is part of the laser series. Article 10133599. It is used as a diffuse reflection sensor. Works at voltage within 12-30 DC. The connection is made via an m12 connector. The output is npn with light triggering.
Featuring an optimum operating distance of 40 to 80 mm, this sensor operates effectively in various environments, with an operating temperature range of -10 to +50 °C. It also includes built-in reverse polarity protection and a durable die-cast zinc housing, making it suitable for industrial applications.
| optimum operating distance | 40 … 80 mm |
| voltage supply range +Vs | 12 … 30 VDC |
| output function | light operate |
| distance to focus | 80 mm |
| sensing distance Tw | 0 … 250 mm |
| width / diameter | 15,4 mm |
| manufacter SKU | OZDM 16N1001/S14 |
| response time / release time | < 0,05 ms |
| light source | pulsed red laser diode |
| wave length | 650 nm |
| housing material | die-cast zinc |
| reverse polarity protection | yes |
| output circuit | NPN |
| height / length | 50 mm |
| operating temperature | -10 … +50 °C |
| output current | < 200 mA |
| detectable remission difference (on grey) | > 8 % |
| type | rectangular |
| sensitivity adjustment | potentiometer, 14 turn |
| voltage drop Vd | < 2 VDC |
| front (optics) | glass |
| repeat accuracy | < 0,1 mm at laser focus |
| protection class | IP 67 |
| depth | 50 mm |
| current consumption typ. | 60 mA |
| output indicator | LED yellow |
| current consumption max. (no load) | 65 mA |
| laser class | 1 |
| type | diffuse contrast sensor |
| connection types | connector M12 4 pin |
| short circuit protection | yes |
