Solid Shaft HeavyDuty Encoder, an incremental encoder designed for optimal performance. With HTL/TTL output capabilities, it ensures reliability over long cable lengths up to 350 m.
Built to withstand extreme shock and vibrations, this encoder features a unique two-sided insulated bearing system.
Solid shaft diam. 11 mm with EURO flange B10
| Baumer Article no | 11191144 |
| Voltage supply | 4.75…30 VDC |
| Short-circuit proof | Yes |
| Consumption w/o load | 100 mA |
| Initializing time | 500 ms after power on |
| Pulses per revolution | 1 … 131072 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Magnetic |
| Output signals | A+, B+, R+, A-, B-, R-Error output nE+, nE- |
| Output stages | TTL/HTL (Vin = Vout) |
| Programming interface | RS485 (600 m) |
| Programmable parameters | Pulse numberSwitch-off and switch-on speedsSwitching delay time |
| Diagnostic function | Function control |
| Status indicator | 4 LEDs in device back side |
| Interference immunity | EN 61000-6-2 |
| Emitted interference | EN 61000-6-3 |
| Approval | CEUL approval / E217823EAC |
| Switching accuracy | ± 2 % (or 1 Digit) |
| Switching outputs | 1 output (Open collector) |
| Output switching capacity | 30 VDC; 100 mA |
| Switching hysteresis | 10 … 100 % adjustable |
| Switching delay time | 20 ms |
| Size (flange) | ø115 mm |
| Shaft type | ø11 mm solid shaft |
| Admitted shaft load | 450 N axial650 N radial |
| Flange | EURO flange B10Housing foot B3 |
| Protection EN 60529 | IP 66/IP 67 |
| Operating speed | 12000 rpm |
| Range of switching speed | ns (off) = ±2…12000 rpm, factory setting 6000 rpm |
| Operating torque typ. | 10 Ncm |
| Rotor moment of inertia | 1 kgcmВ² |
| Material | Housing: aluminium alloyShaft: stainless steel |
| Operating temperature | -40…+95 °C |
| Relative humidity | 95 % non-condensing |
| Resistance | IEC 60068-2-6Vibration 30 g, 10-2000 HzIEC 60068-2-27Shock 400 g, 1 ms |
| Corrosion protection | IEC 60068-2-52 Salt mistfor ambient conditions CX (C5-M) according to ISO 12944-2 |
| Connection | Terminal boxFlange connector M23 |
| Weight approx. | 1.9 kg (depending on version) |
This encoder is equipped with advanced features for programming and diagnostics, ensuring it meets the demands of various applications. With a robust construction designed for harsh environments, it guarantees long-lasting performance and reliability. Ideal for industries requiring precise motion control, the Solid Shaft HeavyDuty Encoder is a top choice for engineers and designers alike.
