Distance sensor
SKU:
RR30.DAJ2-GGPI.9VF
0.00€
Out of stock
One click request
Baumer Distance Sensor, art. 11221309, designed for precision measurement in a variety of applications.
- Features a universal measurement range of 0.3 m to 12 m (up to 18 m with IO-Link).
- Equipped with push-pull and IO-Link output for versatile connectivity.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11221309 |
| Scanning range Sd | 0.3 … 12 m |
| Scanning range close limit Sdc | 0.3 … 12 m |
| Scanning range far limit Sde | 0.3 … 12 m |
| Version | IO-Link dual channel |
| Repeat accuracy | 1 mm |
| Response time ton | < 40 ms |
| Release time toff | < 40 ms |
| Temperature drift | В± 10 mm (Full Scale) |
| Power-up drift | Compensated after 20 min. |
| Adjustment | IO-Link |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Carrier frequency | 122 … 123 GHz |
| Band width | 1 GHz |
| Range resolution | 500 mm |
| Hysteresis typ. | 5 % Sde |
| Linearity error | В± 10 mm |
| Modulation type | FMCW |
| Transmitting power (EIRP) | < +20 dBm |
| Aperture angle | 6 ° |
| MTTF | > 126 years |
| Approvals/certificates | EcolabFCC / CFR-47 part 15 (USA)RSS-210 Issue 10 (Canada)EN 305 550-1 V.1.2.1 (European Union)EN 305 550-2 V.1.2.1 (European Union) |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Output circuit | IO-Link / push-pull |
| Output current | < 100 mA< 50 mA (out 2) |
| Voltage drop Vd | < 2.5 VDC |
| Type | Cylindrical threaded |
| Housing material | Stainless steel 1.4404 (V4A) |
| Width / diameter | 30 mm |
| Height / length | 107 mm |
| Connection types | Connector M12 |
| Operating temperature | -40 … +65 °C |
| Storage temperature | -40 … +85 °C |
| Protection class | IP 68/69K & proTect+ |
| Interface | IO-Link V1.1 |
| Baud rate | 230,4 kBaud (COM 3) |
| Cycle time | 4 ms |
| Process data length | 208 Bit |
| Process data structure | Bit 0 = SSC1 (distance)Bit 1 = SSC2 (distance)Bit 2 = qualityBit 3 = alarmBit 5 = SSC4 (counter)Bit 8-15 = scale factorBit 16-47 = 32 Bit measurementBit 48-207 = 5 Peak (32 Bit Daten) |
| IO-Link port type | Class A |
| Additional data | DistanceExcess gainOperating cyclesOperating hoursBoot cyclesOperating voltageDevice temperatureHistogramsVelocity |
| Adjustable parameters | Switching pointSwitching hysteresisMeasured value filteringMeasuring rangeTime filtersOutput logicOutput circuitCounterAnalog output characteristicLED status indicatorsDeactivate the sensor elementFind Me functionSwitching window definitionSignal sensitivitySignal selection (1. / 2. / strongest / last)Tracking mode |
| Predefined preference profiles | Precise (standard)Fill level fluid (slow)Fill level fluid (fast)Fill level solidFast detectionTracking (slow)Tracking (standard)Tracking (fast) |
This robust distance sensor is ideal for various applications, including level measurement in large containers. With features like a narrow beam opening angle and easy integration with IO-Link, it provides reliable performance for all measurement tasks.
