Industrial camera
SKU:
VAX-50C.I.NVX
0.00€
Out of stock
One click request
VAX-50C.I.NVX, a state-of-the-art industrial camera designed for high-performance imaging. With a 5 Megapixel resolution and NVIDIA Jetson Xavier NX, this camera delivers stunning color accuracy and speed.
Manufacturer:
Baumer
Description:
| Baumer Article no | 11702239 |
| Processor configuration | NVIDIA Jetson Xavier NX |
| GPU data | 384 Core Volta GPU |
| CPU data | 6-Core Carmel ARM |
| AI data | 2 x NVDLA Engines |
| Memory RAM | 8 GB LPDDR4x |
| Memory Flash | 16 GB eMMC 5.1 |
| Sensor | Sony IMX250 Gen2 |
| Mono/Color | Color |
| Sensor type | 2/3″ CMOS |
| Shutter type | Global shutter |
| Resolution | 2448 x 2048 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Image formats, interface frame rate max. | Full Frame, 2448 x 2048 px, max. 73 fpsBinning 2×2, 1224 x 1024 px, max. 76 fpsBinning 2×1, 1224 x 2048 px, max. 76 fpsBinning 1×2, 2448 x 1024 px, max. 76 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 2448 x 2048 px, max. 77 fps |
| Pixel formats | BayerRG8BayerRG10BayerRG12BayerRG12 PackedMono8Mono10Mono12Mono12 PackedRGB8BGR8 |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | MonoRaw BayerRGBBGR |
| Color processing | Integrated color processor for high quality color calculation |
| Auto Functions | Exposure AutoGain AutoWhite Balance AutoColor Transformation Auto |
| Image Pre-processing | Image Flipping (X/Y)Color Processing (RGB, BGR, Mono)Color Enhancement (with optimized ColorTransformationMatrix)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)PWM (PWM Duration / PWM Duty Cycle)4 power outputs with up to 120 W (max. 48 V / 2.5 A)Selectable Output format (e.g. Tri State, Push Pull)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 445 MB31 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | GigEUSB 3.0RS232 |
| Process interface | M12 / 12 pins a-coded (SACC-CI-M12MS-12CON-L180) |
| Power supply | via M12/12 pins a-coded |
| Lens mount | C-mount |
| Width | 70 mm |
| Height | 70 mm |
| Depth | 120 mm |
| Weight | 650 g |
| Material | aluminum, hard-anodized |
| Power consumption | approx. 17,9 W @ 73 fps |
| Operating temperature | 0 … +60 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 65 (with mounted tube and cable)IP 67 (with mounted tube and cable) |
| Lines | 1 input line1 output line |
| Output line sources | OffExposure ActiveTimer1Readout ActiveUser0User1User2TriggerReady |
| Conformity | CERoHS |
This camera is engineered for superior performance in diverse environments, ensuring reliability and efficiency. Its robust construction with aluminum, hard-anodized finish, makes it suitable for various industrial applications.
