Discover the power of the Baumer Industrial Camera, equipped with a Sony IMX273 sensor and capable of delivering stunning 1440 x 1080 pixel resolution. With a frame rate of 79 fps and Gigabit Ethernet connectivity, this camera is designed for high-performance industrial applications.
The Baumer Industrial Camera features Gigabit Ethernet and a 1.5 Megapixel monochrome sensor, making it ideal for precise imaging needs. With advanced specifications such as a global shutter and a dynamic range of 70.5 dB, it ensures high-quality image capture even in challenging conditions. Additional features like customizable trigger sources and a robust internal image buffer enhance its functionality, providing versatility for various industrial settings.
| Baumer Article no | 11182970 |
| Sensor | Sony IMX273 Gen2 |
| Mono/Color | Mono |
| Sensor type | 1/2.9″ CMOS |
| Shutter type | Global shutter |
| Resolution | 1440 x 1080 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.09 e- |
| Saturation capacity | 9231 e- |
| Dynamic range | 70.5 dB |
| Signal-to-noise ratio | 39.7 dB |
| Quantum efficiency | 65.1 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 1440 x 1080 px, max. 79 fpsBinning 2×2, 720 x 540 px, max. 289 fpsBinning 2×1, 720 x 1080 px, max. 120 fpsBinning 1×2, 720 x 540 px, max. 120 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 1440 x 1080 px, max. 121 fpsFull Frame, 1440 x 1080 px, max. 121 fps |
| Pixel formats | Mono8Mono10Mono12Mono12 Packed |
| Color models | Mono |
| Basic Functions | ExposureGain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain Auto |
| Image Pre-processing | Image Flipping (X/Y)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 36 MB8 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer Rate 100 Mbits/sec, Connector: 8P8C Modular Jack (RJ45), screwable type |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via M8 / 8 pins or Power over Ethernet (PoE) |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 49 mm |
| Weight | 120 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Voltage supply range +Vs | 12 … 24 V DC (external power supply)36 … 57 V DC (Power over Ethernet) |
| Power consumption | approx. 2,4 W @ 12 VDC and 79 fpsapprox. 2,9 W @ 48 VDC (PoE) and 79 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSEACBIS-CRS (R-41207004) |
