Experience high-definition imaging with the Baumer Industrial Camera, featuring a resolution of 1920 x 1200 px. This camera utilizes the onsemi PYTHON2000 sensor and supports a maximum frame rate of 53 fps, making it ideal for industrial applications.
The Baumer Industrial Camera offers Gigabit Ethernet connectivity and delivers stunning 2.3 Megapixel monochrome images. With its global shutter technology, it ensures sharp images even under fast-moving conditions. This camera is equipped with advanced features including adjustable frame rates and a robust internal image buffer.
| Baumer Article no | 11165829 |
| Sensor | onsemi PYTHON2000 |
| Mono/Color | Mono |
| Sensor type | 2/3″ CMOS |
| Shutter type | Global shutter |
| Resolution | 1920 x 1200 px |
| Pixel size | 4.8 x 4.8 Вµm |
| Exposure time | 0.02 … 1000 ms |
| Dark noise | 10.93 e- |
| Saturation capacity | 9207 e- |
| Dynamic range | 57.9 dB |
| Signal-to-noise ratio | 39.6 dB |
| Quantum efficiency | 57.2 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 1920 x 1200 px, max. 53 fpsBinning 2×2, 960 x 600 px, max. 59 fpsBinning 2×1, 960 x 1200 px, max. 59 fpsBinning 1×2, 1920 x 600 px, max. 59 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 1920 x 1200 px, max. 59 fps |
| Pixel formats | Mono8Mono10 |
| Analog controls | Gain (0 … 12 dB)Offset (0 … 63 LSB 10 Bit) |
| Color models | Mono |
| Basic Functions | ExposureGain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain Auto |
| Image Pre-processing | Image Flipping (X/Y)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 53 MB8 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer Rate 100 Mbits/sec, Connector: 8P8C Modular Jack (RJ45), screwable type |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via M8 / 8 pins or Power over Ethernet (PoE) |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 49 mm |
| Weight | 120 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Voltage supply range +Vs | 12 … 24 V DC (external power supply)36 … 57 V DC (Power over Ethernet) |
| Power consumption | approx. 2,9 W @ 12 VDC and 53 fpsapprox. 3,5 W @ 48 VDC (PoE) and 53 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSKC (MISP-REI-BkR-VCXG-53M)EACBIS-CRS (R-41207004) |
