Baumer VCXG-51M Industrial Camera, featuring a stunning resolution of 2448 x 2048 px. Equipped with the advanced Sony IMX264 sensor, this camera captures clear and detailed images at 24 fps.
The Baumer VCXG-51M is a state-of-the-art industrial camera designed for demanding applications. With Gigabit Ethernet connectivity and a 5.0 Megapixel monochrome sensor, it ensures fast data transfer and high-quality image acquisition. Its global shutter technology allows for precise capturing of fast-moving objects, making it ideal for various industrial tasks. Additionally, the camera supports a wide range of exposure times and has excellent dynamic range, ensuring optimal performance in diverse lighting conditions.
| Baumer Article no | 11165952 |
| Sensor | Sony IMX264 Gen2 |
| Mono/Color | Mono |
| Sensor type | 2/3″ CMOS |
| Shutter type | Global shutter |
| Resolution | 2448 x 2048 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.15 e- |
| Saturation capacity | 10396 e- |
| Dynamic range | 71.3 dB |
| Signal-to-noise ratio | 40.2 dB |
| Quantum efficiency | 65.6 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 2448 x 2048 px, max. 24 fpsBinning 2×2, 1224 x 1024 px, max. 36 fpsBinning 2×1, 1224 x 2048 px, max. 36 fpsBinning 1×2, 2448 x 1024 px, max. 36 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 2448 x 2048 px, max. 36 fps |
| Pixel formats | Mono8Mono10Mono12Mono12 Packed |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | Mono |
| Basic Functions | ExposureGain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain Auto |
| Image Pre-processing | Image Flipping (X/Y)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 115 MB8 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer Rate 100 Mbits/sec, Connector: 8P8C Modular Jack (RJ45), screwable type |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via M8 / 8 pins or Power over Ethernet (PoE) |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 49 mm |
| Weight | 120 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Voltage supply range +Vs | 12 … 24 V DC (external power supply)36 … 57 V DC (Power over Ethernet) |
| Power consumption | approx. 2,6 W @ 12 VDC and 24 fpsapprox. 3,1 W @ 48 VDC (PoE) and 24 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSKC (MISP-REI-BkR-VCXG-51C)EACBIS-CRS (R-41207004) |
