Baumer VCXU-123M Industrial Camera features a high resolution of 4096 x 3000 pixels, powered by advanced Sony IMX253 sensor. With a frame rate of 30 fps and USB 3.0 connectivity, it is ideal for various industrial applications.
This USB 3.0 Industrial Camera offers an impressive 12.3 Megapixel monochrome image quality. Equipped with a global shutter and a robust 1.1″ CMOS sensor, it ensures precise imaging even in dynamic environments. The camera supports multiple image formats and has extensive control options for optimal performance.
| Baumer Article no | 11165898 |
| Sensor | Sony IMX253 Gen2 |
| Mono/Color | Mono |
| Sensor type | 1.1″ CMOS |
| Shutter type | Global shutter |
| Resolution | 4096 x 3000 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.2 e- |
| Saturation capacity | 10179 e- |
| Dynamic range | 71 dB |
| Signal-to-noise ratio | 40.1 dB |
| Quantum efficiency | 65.4 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 4096 x 3000 px, max. 30 fpsBinning 2×2, 2048 x 1500 px, max. 116 fpsBinning 2×1, 2048 x 3000 px, max. 31 fpsBinning 1×2, 4096 x 1500 px, max. 31 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 4096 x 3000 px, max. 31 fps |
| Pixel formats | Mono8Mono10Mono12Mono12 Packed |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | Mono |
| Basic Functions | ExposureGain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain Auto |
| Image Pre-processing | Image Flipping (X/Y)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftware |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 458 MB13 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | USB 3.0, Transfer Rate 5000 Mbits/sec, Connector: USB 3.0 Micro B |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via USB 3.0 interface |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 38 mm |
| Weight | 90 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Power consumption | approx. 3,7 W @ 30 fps |
| Operating voltage | 5 VDC (via USB3.0 interface) |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSEACBIS-CRS (R-41207004) |
