Baumer VCXU-50MP Industrial Camera offers high-resolution imaging with 2448 x 2048 pixels. Featuring a Sony IMX250MZR sensor, it delivers exceptional performance at 73 fps using a USB 3.0 interface.
This USB 3.0, 5 Megapixel, mono polarized industrial camera is designed for demanding applications. It utilizes a global shutter to capture images without distortion, ensuring clarity and precision. With a dynamic range of 70.6 dB and a signal-to-noise ratio of 39.7 dB, the VCXU-50MP excels in various lighting conditions.
| Baumer Article no | 11206488 |
| Sensor | Sony IMX250MZR |
| Mono/Color | Mono polarized |
| Sensor type | 2/3″ CMOS |
| Shutter type | Global shutter |
| Resolution | 2448 x 2048 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.09 e- |
| Saturation capacity | 9327 e- |
| Dynamic range | 70.6 dB |
| Signal-to-noise ratio | 39.7 dB |
| Quantum efficiency | 24.5 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 2448 x 2048 px, max. 73 fpsBinning 2×2, 1224 x 1024 px, max. 77 fpsBinning 2×1, 1224 x 2048 px, max. 77 fpsBinning 1×2, 2448 x 1024 px, max. 77 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 2448 x 2048 px, max. 77 fps |
| Pixel formats | Mono8Mono10Mono12Mono12 Packed |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | MonoMono polarized |
| Basic Functions | ExposureGain / Color Gain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | White Balance Auto |
| Image Pre-processing | Image Flipping (X/Y)Color Processing (RGB, BGR, Mono)Color Enhancement (with optimized ColorTransformationMatrix)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftware |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred image |
| Additional Functions | User SetIntegrated temperature sensor |
| Internal image buffer | 445 MB31 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | USB 3.0, Transfer Rate 5000 Mbits/sec, Connector: USB 3.0 Micro B |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via USB 3.0 interface |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 38 mm |
| Weight | 90 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Power consumption | approx. 3,3 W @ 73 fps |
| Operating voltage | 5 VDC (via USB3.0 interface) |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSEAC |
