The VCXU-65C.R Industrial Camera offers exceptional image quality with a resolution of 3072 x 2048 pixels. Equipped with a Sony IMX178 sensor, it captures images at 47 frames per second, making it ideal for dynamic environments.
Experience the power of USB 3.0 connectivity with the VCXU-65C.R Industrial Camera, featuring a 6.2 Megapixel color sensor. This camera is designed for high-performance applications, providing a dynamic range of 71.9 dB and a signal-to-noise ratio of 41.5 dB. With a compact design and robust construction, it meets IP 40 protection standards, ensuring reliability in various industrial settings.
| Baumer Article no | 11175751 |
| Sensor | Sony IMX178 |
| Mono/Color | Color |
| Sensor type | 1/1.8†CMOS |
| Shutter type | Rolling shutterGlobal reset shutter |
| Resolution | 3072 x 2048 px |
| Pixel size | 2.4 x 2.4 µm |
| Exposure time | 0.014 … 60000 ms |
| Dark noise | 2.89 e- |
| Saturation capacity | 14231 e- |
| Dynamic range | 71.9 dB |
| Signal-to-noise ratio | 41.5 dB |
| Quantum efficiency | 56.4 % @ 465 nm61.7 % @ 536 nm47.5 % @ 631 nm |
| Image formats, interface frame rate max. | Full Frame, 3072 x 2048 px, max. 47 fpsBinning 2×2, 1536 x 1024 px, max. 47 fpsBinning 2×1, 1536 x 2048 px, max. 47 fpsBinning 1×2, 3072 x 1024 px, max. 47 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 3072 x 2048 px, max. 47 fps |
| Pixel formats | BayerRG8BayerRG10BayerRG12BayerRG12 PackedMono8Mono10Mono12Mono12 PackedRGB8BGR8 |
| Analog controls | Gain (0 … 26 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | MonoRaw BayerRGBBGR |
| Basic Functions | ExposureGain / Color Gain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain AutoWhite Balance AutoColor Transformation Auto |
| Image Pre-processing | Image Flipping (X/Y)Color Processing (RGB, BGR, Mono)Color Enhancement (with optimized ColorTransformationMatrix)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftware |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 450 MB25 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | USB 3.0, Transfer Rate 5000 Mbits/sec, Connector: USB 3.0 Micro B |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via USB 3.0 interface |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 38 mm |
| Weight | 90 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Power consumption | approx. 3,0 W @ 47 fps |
| Operating voltage | 5 VDC (via USB3.0 interface) |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 ° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSEAC |
