Industrial Camera
SKU:
VLXT-31C.I
0.00€
Out of stock
One click request
VLXT-31C.I Industrial Camera, featuring a high-resolution of 2048 x 1536 px and powered by a Sony IMX252 sensor.
With advanced capabilities including 216 fps and 10 GigE interface, this camera is ideal for various industrial applications.
Manufacturer:
Baumer
Description:
Gigabit Ethernet, 3.1 Megapixel, Color
| Baumer Article no | 11194257 |
| Sensor | Sony IMX252 Gen2 |
| Mono/Color | Color |
| Sensor type | 1/1.8″ CMOS |
| Shutter type | Global shutter |
| Resolution | 2048 x 1536 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Image formats, interface frame rate max. | Full Frame, 2048 x 1536 px, max. 216 fpsBinning 2×2, 1024 x 768 px, max. 216 fpsBinning 2×1, 1024 x 1536 px, max. 216 fpsBinning 1×2, 2048 x 768 px, max. 216 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 2048 x 1536 px, max. 216 fps |
| Pixel formats | BayerRG8BayerRG10BayerRG12BayerRG12 PackedMono8Mono10Mono12Mono12 PackedRGB8BGR8 |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | MonoRaw BayerRGBBGR |
| Basic Functions | ExposureGain / Color Gain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image)Multi ROI |
| Auto Functions | Exposure AutoGain AutoWhite Balance AutoColor Transformation Auto |
| Image Pre-processing | Image Flipping (X/Y)Color Processing (RGB, BGR, Mono)Advanced 5×5 Color Processing (RGB, BGR, Mono)Color Enhancement (with optimized ColorTransformationMatrix)LUT / GammaShading CorrectionEdge SharpeningNoise Reduction |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Action CMD Request IDTrigger ID inside ChunkAdditional Output Modes (e.g. Trigger Ready)PWM (PWM Duration / PWM Duty Cycle)Selectable Output format (e.g. Tri State, Push Pull)Chunk data inside transferred imageEncoder support via Counter End trigger source4 power outputs with up to 120 W (max. 48 V / 2.5 A) |
| Time synchronization IEEE 1588 | IEEE 1588 / Master and Slave functionIEEE 1588 / Scheduled Action CMDIEEE 1588 / Synchronized Acquisition Framerate |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Lens control | Corning liquid lens |
| Sequencer | Automated control for series of images using different sets of parameters |
| Sequencer parameter | Exposure timegain factorOutputROI Offset xROI Offset y |
| Internal image buffer | 1024 MB307 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | 10 Gigabit Ethernet, Transfer rate 10000 Mbits/sec, Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer rate 100 Mbits/sec, Connector: M12 / 8-pol x-coded (SACC-CI-M12FS-8CON-L180-10G) |
| Process interface | M12 / 12 pins a-coded (SACC-CI-M12MS-12CON-L180) |
| Power supply | via M12/12 pins a-coded |
| Lens mount | C-mount |
| Width | 60 mm |
| Height | 60 mm |
| Depth | 99.7 mm |
| Weight | 485 g |
| Material | aluminum |
| Voltage supply range +Vs | 19.2 … 28.8 V DC (external power supply) |
| Power consumption | approx. 10.3 W @ 24 VDC and 216 fps |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40IP 54 (with mounted tube and cable)IP 65 (with mounted tube and cable)IP 67 (with mounted tube and cable) |
| Lines | 2 input lines4 power output lines with pulse width modulation (PWM) (max. 48 V / max. 2,5 A)RS232 |
| Conformity | CERoHSEACUL recognized |
This camera is engineered for high-performance imaging, making it suitable for a variety of industrial applications. Its robust design ensures durability and reliability in demanding environments.
