The Vision Sensor XC800 offers advanced imaging capabilities with integrated PROFINET and EtherNet/IP interfaces. Equipped with the FEX image processor, it ensures precise part location and flexible result conjunction.
| Baumer Article no | 11166807 |
| Resolution | 1280 x 960 px |
| Sensor type | 1/3″ CCD, monochrome |
| Illumination | external, available as accessory |
| Illumination connection | direct (integrated VeriFlashВ® flash controller) |
| High-resolution mode | max. 32 inspections per second |
| High-speed mode (limited resolution) | max. 54 inspections per second |
| Number of jobs (products) | 255 |
| Features per job | 32 |
| Signal processing | Baumer FEXВ® 4.0 |
| Defect image memory | 8 |
| Lens | C-mount |
| Nominal voltage power supply | 24 V +- 25% |
| Nominal voltage power supply (add-on) | Class 2 according to NEC / protection class III |
| Nominal voltage power supply (info) | The device is intended for supply from an isolated limited power source according to UL61010-1, 3rd ed cl. 9.4 or a limited energy source according to UL60950-1 or Class 2 according to NEC. |
| Power consumption | max. 42 W (with I/O and lighting) |
| Inputs | 8 … 30 V (polarity protected) |
| Digital inputs | 5 inputstriggerjob selectionexternal teach-inencoders (CH-A, CH-B) 500 kHz |
| Outputs | PNP Ipeak = 100 mA and Ieff = 50 mA (short-circuit proof) |
| Digital outputs | 5 outputsPass / FailFlash SyncAlarmCamera ReadyOutput Enable |
| Initial setup | Ethernet (10BASE-T / 100BASE-TX) |
| Process interface | PROFINET (CC-A)EtherNet/IPâ„¢TCP/UDP (Ethernet) |
| Visualization | configurable web interface with MultiViewer function |
| Width | 53 mm (without lens/tube) |
| Height | 99.5 mm (without lens/tube) |
| Depth | 49.8 mm (without lens/tube) |
| Weight | 300 g (without lens/tube) |
| Material | housing: aluminum, cover glass XC tube: PMMA |
| Operating temperature | +5 … +55 В°C @ T = measurement point |
| Storage temperature | -20 … +70 В°C |
| Humidity | 0 … 90 % (non-condensing) |
| Protection class | IP 67 (with tube) |
| Vibration load | IEC 60068-2-6IEC 60068-2-64 |
| Mechanical shock resistance | EN 60068-2-27 |
| Barcode | 2/5 Industrial 2/5 InterleavedCodabarCode 39Code 93Code 128PharmaCodeEAN 8EAN 13UPC-AUPC-EGS1 DataBarGS1 128 |
| Matrix code | DataMatrix (ECC 200)GS1-DataMatrixQR-CodePDF417 |
| Font | many font styles (recommended: sans serif, proportional)Dot Matrixcharacters: A-Z a-z 0-9 + – . : / ( ) |
| Part location | part location on contourspart location on edgespart location on circlepart location on text line |
| Geometry | Distancecircleanglecount edgespoint positionedge characteristics |
| Feature comparison | count contour pointscontour comparisonbrightnesscontrastarea sizecount areaspattern comparisonfind object positions |
| Identification | BarcodeMatrix codetext |
| Voltage | 12 V DC or 24 V DC (permanent)24 V DC or 48 V DC (pulsed) |
| Current | Imax = 800 mA at 24 V DC (permanent) (В±10 %, at least В± 100 mA, at 25 В°C)Imax = 4 A at 48 V DC (pulsed) (+10/-20 %, at least В± 100 mA, at 25 В°C) |
| Flash time | max. 1 ms (Duty Cycle max. 1:10) |
| Conformity | CERoHSEACKC (R-R-BkR-VeriSens-XC-IP)UL recognized |
| Flash memory size | 2000 Mbit Flash S34ML02G100BHI0000 |
This device is designed for both high-resolution and high-speed inspection modes, making it versatile for various industrial applications. The XC800 sensor is perfect for precise part location and efficient signal processing, ensuring optimal performance in demanding environments.
