The Vision sensor XF700 is an advanced imaging solution equipped with integrated PROFINET and EtherNet/IP interfaces. It features the innovative FEX image processor and intelligent 3D color assistance for precise part location and inspection.
| Baumer Article no | 11197478 |
| Resolution | 752 x 480 px |
| Sensor type | 1/3″ CMOS, color |
| Illumination | integrated, LED white |
| LED class | risk group 1 (low risk, EN 62471:2008) |
| High-resolution mode | max. 50 inspections per second |
| Object distance min. | 50 mm |
| Object distance max. | 450 mm |
| Number of jobs (products) | 255 |
| Features per job | 32 |
| Signal processing | Baumer FEXВ® 4.0 |
| Defect image memory | 32 |
| Lens | 12 mm |
| Nominal voltage power supply | 24 V +- 25% |
| Nominal voltage power supply (add-on) | Class 2 according to NEC / protection class III |
| Nominal voltage power supply (info) | The device is intended for supply from an isolated limited power source according to UL61010-1, 3rd ed cl. 9.4 or a limited energy source according to UL60950-1 or Class 2 according to NEC. |
| Power consumption | max. 18 W (with I/O) |
| Inputs | 8 … 30 V (polarity protected) |
| Digital inputs | 5 inputstriggerjob selectionexternal teach-inencoders (CH-A, CH-B) 500 kHz |
| Outputs | PNP Ipeak = 100 mA and Ieff = 50 mA (short-circuit proof) |
| Digital outputs | 5 outputsPass / FailFlash SyncAlarmCamera ReadyOutput Enable |
| Initial setup | Ethernet (10BASE-T / 100BASE-TX) |
| Process interface | PROFINET (CC-A)EtherNet/IPâ„¢TCP/UDP (Ethernet) |
| Visualization | configurable web interface with MultiViewer function |
| Width | 53 mm |
| Height | 99.5 mm |
| Depth | 38 mm |
| Weight | 250 g |
| Material | housing: aluminum, cover glass: PMMA |
| Operating temperature | +5 … +60 В°C @ T = measurement point |
| Storage temperature | -20 … +70 В°C |
| Humidity | 0 … 90 % (non-condensing) |
| Protection class | IP 67 |
| Vibration load | IEC 60068-2-6IEC 60068-2-64 |
| Mechanical shock resistance | EN 60068-2-27 |
| Part location | part location on contourspart location on edgespart location on circlepart location on text line |
| Geometry | Distancecircleanglecount edgespoint positionedge characteristics |
| Feature comparison | count contour pointscontour comparisonbrightnesscontrastarea sizecount areaspattern comparisoncolor identificationcolor positioning |
| Conformity | CERoHSEACUL |
| Flash memory size | 2000 Mbit Flash S34ML02G100BHI0000 |
With the Vision sensor XF700, users can leverage advanced part location techniques and intelligent processing capabilities to enhance their production line efficiency. This camera is designed for a wide range of applications, ensuring reliability and precision in every inspection.
