Out of stock
The Inductive sensor from Pepperl+Fuchs is designed for reliable non-contact detection of metallic objects. With a rated operating distance of 40 mm, this sensor is suitable for various industrial applications requiring precise sensing capabilities.
The Pepperl+Fuchs Inductive Proximity Sensors are designed for a wide range of automation and control applications where reliable detection of metallic objects is essential. These sensors utilize an AC Make/Break function, providing robust performance in industrial environments. The sensors are constructed from durable PBT housing material, ensuring resilience against harsh conditions.
Common applications for these sensors include machine automation, conveyor systems, and material handling, where accurate detection of position or presence is critical. Their 2-wire output configuration simplifies installation and integration into existing systems, while the non-embeddable design allows for easy surface mounting. The sensors operate effectively with AC voltage, making them versatile for various electrical setups.
| General specifications | ||
| Switching element function | AC |
|
| Rated operating distance | 40 mm | |
| Installation | non-flush | |
| Output polarity | AC | |
| Assured operating distance | 0 … 32.4 mm | |
| Reduction factor rAl | 0.5 | |
| Reduction factor rCu | 0.45 | |
| Reduction factor r304 | 0.8 | |
| Nominal ratings | ||
| Operating voltage | 20 … 253 V 1) | |
| Switching frequency | 0 … 20 Hz | |
| Hysteresis | 1 … 10 typ. 5 % | |
| Voltage drop | less than or equal to 5 V | |
| Momentary current (20 ms, 0.1 Hz) |
0 … 3000 mA | |
| Operating current | 8 … 500 mA | |
| Off-state current | 0.5 … 1.95 mA typ. 1.2 mA | |
| Operating voltage indicator | LED, green | |
| Switching state indicator | LED, yellow | |
| Approvals and certificates | ||
| CCC approval | Certified by China Compulsory Certification (CCC) | |
| Ambient conditions | ||
| Ambient temperature | -25 … 70 �C (-13 … 158 �F) | |
| Storage temperature | -25 … 85 �C (-13 … 185 �F) | |
| Mechanical specifications | ||
| Core cross-section | up to 2.5 mm2 | |
| Housing material | PBT | |
| Sensing face | PBT | |
| Degree of protection | IP68 | |
| Note | 1) In the temperature range below 0 �C, permissible operating voltage Ub 80…253 V Safety fuse less than or equal to 2 A (quick-blow) according to IEC 60127-2 Sheet 1 Recommendation: after a short circuit, check that the device is functioning correctly. |
|
