Out of stock
Profile camera offers precise measurement capabilities with an output of a calibrated 2D point cloud, perfect for advanced external PC processing.
Its intuitive web interface allows for easy sensor parameterization, while free SDK provides example code for seamless integration.
| Baumer Article no | 11218605 |
| Type | Measuring mode: Profile in x-z |
| Measurement range MR | 100 mm |
| Clearance distance | 150 mm |
| Working range (Sdc … Sde) | 150 … 250 mm |
| Reference distance | 200 mm |
| Field of view (@Sdc … Sde) | 75 mm … 125 mm |
| Resolution X (@Sdc … Sde) | 125 … 210 Вµm |
| Profiles per second | 200 … 800 Hz |
| Profile points | 600 pixel |
| Resolution Z (@Sdc … Sde) | 12 … 18 Вµm |
| Repeat accuracy Z | 10 Вµm |
| Linearity deviation Z | В± 0.1 % MR |
| Temperature drift | В± 0.04 %Sde/K |
| Laser class | 2 |
| Laser wavelength | Red (660 nm) |
| Max. laser power | 4.5 mW |
| Light point shape (at reference distance) | Line Length (x) 125 mmLine Width (z) < 400 Вµm |
| Software / parametrisation | Integrated Webserver for parametrisation |
| Interfaces / output circuit | Fast Ethernet 100-MBit/s |
| Protocols | UDP, SDK (C#, C++, .NET, Python) |
| Voltage supply range +Vs | 18 … 30 VDC |
| Switching outputs | 1 x Alarm Output (Push Pull) |
| Power supply | typ. 2.4W (100 mA max at 24 V)IEEE 802.3af Power over Ethernet (PoE) |
| Electrical connection | M12 12-pol, A-coded, male |
| Ethernet connection | M12 8-pol, X-coded, female |
| Encoder input specifications | 4 Inputs Differential: A/BHTL / TTL availableHigh Level: 2.5 V … +Ub / PoE 2.5 … 24 VLow Level: < 1.5 VMax. Frequency 30kHz |
| Trigger input specification | High Level: 8 V … +Ub / PoE 8 … 24 VLow Level: < 2.5 V |
| Material | Case: Aluminium, Front Cover: Glass |
| Dimensions (W x H x D) | 36 mm x 74 mm x 60 mm |
| Width | 36 mm |
| Height | 74 mm |
| Depth | 60 mm |
| Weight | 270 g |
| Ambient temperature | 0 … + 45 В°C |
| Storage temperature | – 10 … + 60 В°C |
| Ambient humidity | 20 … 85 % |
| Protection class (IEC 60529) | IP65 |
| Vibration (sinusoidal) | 1 mm p-p at f = 10 – 55 Hz, duration 5 min per axis30 min endurance at f = 55 Hz per axisIEC 60068-2-6:2008 |
| Shock (semi-sinusoidal) | 30 g / 11 ms, 6 jolts per axis and directionIEC 60068-2-27:2009 |
| Ambient light immunity | < 25 kLux |
| Conformity | CEUL |
This camera is designed for robust performance in various environmental conditions, ensuring reliability in industrial applications. Its compact design and efficient power consumption make it a versatile choice for precise measurement tasks.
