Baumer Industrial Camera, featuring a resolution of 1440 x 1080 pixels. Equipped with a Sony IMX273 sensor and capable of capturing up to 79 frames per second, this camera is ideal for various industrial applications.
The Baumer Industrial Camera offers exceptional performance with Gigabit Ethernet connectivity and a 1.5 Megapixel monochrome sensor. It features a global shutter for precise image capture, ensuring high-quality results even in dynamic environments. With a wide range of functionalities including adjustable frame rates and extensive internal buffering, this camera is designed for versatility in demanding industrial settings.
| Baumer Article no | 11194678 |
| Sensor | Sony IMX273 Gen2 |
| Mono/Color | Mono |
| Sensor type | 1/2.9″ CMOS |
| Shutter type | Global shutter |
| Resolution | 1440 x 1080 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.06 e- |
| Saturation capacity | 9345 e- |
| Dynamic range | 70.7 dB |
| Signal-to-noise ratio | 39.7 dB |
| Quantum efficiency | 65.6 % @ 536 nm |
| Image formats, interface frame rate max. | Full Frame, 1440 x 1080 px, max. 79 fpsBinning 2×2, 720 x 540 px, max. 289 fpsBinning 2×1, 720 x 1080 px, max. 120 fpsBinning 1×2, 720 x 540 px, max. 120 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 1440 x 1080 px, max. 121 fps |
| Pixel formats | Mono8Mono10Mono12Mono12 Packed |
| Analog controls | Gain (0 … 18 dB)Offset (0 … 63 LSB 10 Bit) |
| Color models | Mono |
| Basic Functions | ExposureGain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain Auto |
| Image Pre-processing | Image Flipping (X/Y)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftwareActionCommand |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)PWM (PWM Duration / PWM Duty Cycle)4 power outputs with up to 120 W (max. 48 V / 2.5 A)Selectable Output format (e.g. Tri State, Push Pull)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 36 MB8 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | Gigabit Ethernet, Transfer rate 1000 Mbits/sec, Fast Ethernet, Transfer rate 100 Mbits/sec, Connector: M12 / 8 pol x-coded, screwable type |
| Process interface | M12 / 12 pins a-coded (SACC-CI-M12MS-12CON-L180) |
| Power supply | via M12/12 pins a-coded or Power over Ethernet (PoE) |
| Lens mount | C-mount |
| Width | 40 mm |
| Height | 40 mm |
| Depth | 50.8 mm |
| Weight | 137 g |
| Material | aluminum, hard-anodized |
| Voltage supply range +Vs | 12 … 24 V DC (external power supply)36 … 57 V DC (Power over Ethernet) |
| Power consumption | approx. 2,4 W @ 12 VDC and 79 fpsapprox. 3,0 W @ 48 VDC (PoE) and 79 fps |
| Flash memory size | 128 kB |
| Operating temperature | -40 … +70 В°C @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40IP 54 (with mounted tube and cable)IP 65 (with mounted tube and cable)IP 67 (with mounted tube and cable)IP 69K (with stainless steel housing accessory) |
| Lines | 4 input lines4 power output lines with pulse width modulation (PWM) (max. 48 V / max. 2,5 A) |
| Conformity | CERoHSEACKC (R-R-BkR-VCXG-15MI) |
