The VCXU-15C Industrial Camera offers stunning image quality with a resolution of 1440 x 1080 pixels. With its high-speed performance of 224 frames per second, it is ideal for various industrial applications.
Equipped with a Sony IMX273 sensor, this camera ensures reliable and accurate color reproduction.
The VCXU-15C Industrial Camera features USB 3.0 connectivity and a 1.5 Megapixel resolution, making it perfect for high-speed imaging tasks. This device includes a global shutter for distortion-free images, ensuring crisp and clear visuals.
With a dynamic range of 70.6 dB and a signal-to-noise ratio of 39.7 dB, it delivers exceptional performance even in challenging lighting conditions. The camera’s compact design and robust construction ensure durability in demanding industrial environments.
| Baumer Article no | 11182974 |
| Sensor | Sony IMX273 Gen2 |
| Mono/Color | Color |
| Sensor type | 1/2.9″ CMOS |
| Shutter type | Global shutter |
| Resolution | 1440 x 1080 px |
| Pixel size | 3.45 x 3.45 Вµm |
| Exposure time | 0.001 … 60000 ms |
| Dark noise | 2.12 e- |
| Saturation capacity | 9412 e- |
| Dynamic range | 70.6 dB |
| Signal-to-noise ratio | 39.7 dB |
| Quantum efficiency | 46.2 % @ 465 nm57.6 % @ 536 nm53.6 % @ 631 nm |
| Image formats, interface frame rate max. | Full Frame, 1440 x 1080 px, max. 224 fpsBinning 2×2, 720 x 540 px, max. 224 fpsBinning 2×1, 720 x 1080 px, max. 224 fpsBinning 1×2, 1440 x 540 px, max. 224 fps |
| Image formats, aquisition frame rate max. (Burst Mode) | Full Frame, 1440 x 1080 px, max. 226 fps |
| Pixel formats | BayerRG8BayerRG10BayerRG12BayerRG12 PackedMono8Mono10Mono12Mono12 PackedRGB8BGR8 |
| Analog controls | Gain (0 … 48 dB)Offset (0 … 255 LSB 12 Bit) |
| Color models | MonoRaw BayerRGBBGR |
| Basic Functions | ExposureGain / Color Gain Trigger / Exposure Active (Flash)Binning 2x2Partial ScanOffsetFree Running Mode (Live Image) |
| Auto Functions | Exposure AutoGain AutoWhite Balance AutoColor Transformation Auto |
| Image Pre-processing | Image Flipping (X/Y)Color Processing (RGB, BGR, Mono)Color Enhancement (with optimized ColorTransformationMatrix)LUT / Gamma |
| Acquisition / Interface | Burst Mode Adjustable FramerateShort Exposure Time EnableDevice Link Throughput LimitInternal Image Buffer |
| Synchronization | free running trigger |
| Trigger sources | HardwareSoftware |
| Trigger delay | 0 … 2 sec, tracking and buffering of up to 256 trigger signals |
| Process Synchronization | EventsTimerTrigger DelayDebouncerCounterSequencerTrigger via Action CMD (GigE)Additional Output Modes (e.g. Trigger Ready)Chunk data inside transferred imageEncoder support via Counter End trigger source |
| Additional Functions | User SetIntegrated temperature sensorReadable additional information (e.g. sensor information)Save Custom Data |
| Internal image buffer | 428 MB96 images (Trigger Mode)1 image (Free Running Mode) |
| Data interface | USB 3.0, Transfer Rate 5000 Mbits/sec, Connector: USB 3.0 Micro B |
| Process interface | M8 / 8 pins (SACC-DSI-M8MS-8CON-M8-L180) |
| Power supply | via USB 3.0 interface |
| Lens mount | C-mount |
| Width | 29 mm |
| Height | 29 mm |
| Depth | 38 mm |
| Weight | 90 g |
| Material | zinc die casting, baked varnish (until 02-2020 nickel-chrome-plated), IP 40 |
| Power consumption | approx. 3,3 W @ 224 fps |
| Operating voltage | 5 VDC (via USB3.0 interface) |
| Flash memory size | 128 kB |
| Operating temperature | 0 … +65 В° @ T = measurement point |
| Humidity | 10 … 90 % (non-condensing) |
| Protection class | IP 40 |
| Lines | 1 input line1 output line2 general purpose lines |
| Conformity | CERoHSEACBIS-CRS (R-41207004) |
